AUTOBAG® Brand Accu-Scale® 220

AUTOBAG® Brand Accu-Scale® 220


The AUTOBAG® Brand Accu-Scale® 220 is a simple, highly sensitive infeed system that accurately weigh-counts small parts. Designed for use with the AUTOBAG® Brand 500 High-Speed Bagging System, the Accu-Scale® 220 provides a complete weigh-count packaging solution.

Utilizing the very latest technology, the AUTOBAG® Brand Accu-Scale 220 is capable of detecting and counting product as light as 0.1 grams. Simply place a sample of the product to be counted into the tray and the scale virtually programs itself to count the product accurately. As more products are added, the weight is instantly measured and the piece count is displayed. Once the desired amount is reached, a foot-pedal-operated flip-tray automatically dispenses each batch into a pre-opened AUTOBAG® Brand plastic bag.

Using system matched AUTOBAG® Brand bags-on-a-roll, the AUTOBAG® Brand Accu-Scale® 220 offers a fast and effective semi-automatic, weigh-count and bagging solution.

Features and Benefits

  • Easy operator access to touch screen for new product set-up and part count read-out
  • When desired count is reached, flip tray is activated by operator and gravity feeds product into bag for heat sealing
  • AutoTouch™ Control Screen from the AUTOBAG® Brand 500 High-Speed Bagging System with decentralized mounting to AUTOBAG® Brand Maximizer for easy operator access
  • Able to count bulk product from 0.1 grams up to 5 pounds in weight – overall sensitivity exceeds 0.1 gram (.003 oz)
  • Ideal for products that tangle or do not flow easy
  • Multi-batch capability for large product applications that exceed the volume of the flip-tray for flexibility
  • Large stainless steel supply table with capacity for up to 1.5 cubic feet of bulk product


This is a table


152 lbs. (69 kg)


115/230 VAC; 50/60 Hz

Air Supply:

.5 CFM/80 psi of clean, dry air
(5.5 CFM required with bagger)


35.5 in. (90.2 cm)


48 in. (122 cm)


55 in. (139.7 cm)

Weighing Capacity:

5 lbs. (2.27 kg)

Weighing Resolution:

0.003 oz. (0.1g)
